GENERAL
+12V Rail Outputs : Single
100% Tested and Verified : Y
ATX12V 2.2 & ESP12V 2.91 Compliant : Y
ATX12V 2.31 Compliant : Y
Compatible with intel ad AMD platforms : Y
UPC Number : 778656052604

TECHNOLOGIES
CrossFire Ready : Y
Hasewell Ready : Y
SLI Ready : Y

RATINGS & EFFICIENCIES
AC Input Current (Arms) : 10A-5A
AC Input Frequency (Hz) : 47/63 Hz
AC Input Voltage (Vac) : 90-264 VAC
Efficiency @ Typical Load : Up to 85%
Energy-Efficiency : 80 Plus Bronze Certified
Maximum Wattage : 750 Watts

OTHER FEATURES
High Reliable 105°C Japanese Capacitors : Y
Solid State Capacitors : Y
Tight voltage regulation (±5%) : Y

LOAD RANGE
Max -12V Output Current (A) : 0.3
Max +12V Output Current (A) : 62
Max +3.3V Output Current (A) : 25
Max +5V Output Current (A) : 25
Max +5VSB Output Current (A) : 3

CABLE CONNECTORS
Fixed FDD : One Connector
Fixed Peripheral : Up to 7 Connectors
Fixed 6+2-pin PCI-E : 4
Fixed ATX12V / EPS12V : One 4+4-pin
Fixed Motherboard Connector : 20+4-Pin
Fixed SATA : Up to 8 Connectors

SAFETY & PROTECTION
Active Power Factor Correction (PFC) : Y
Over Current Protection (OCP) : Y
Over Power Protection (OPP) : Y
Over Temperature Protection : Y
Over Voltage Protection (OVP) : Y
Short Circuit Protection (SCP) : Y
Under Voltage Protection (UVP) : Y

PHYSICAL
Cooling Fan Size (mm) : 135mm Ball Bearing Fan (Black)
INCLUDES
AC Power Cord : 1
Units/Carton : 5
User’s Manual : 1
